Terminales
B
L
C
P
Referencia AWG COLOR HUECO mm mm W mm mm Marca
mm
BCL30014 8 1/4’’ 45.2 19.1 12.7 19.1 9.5 CU
BCL30015 6 1/4’’ 49.3 19.1 12.7 19.1 9.5 CU
45.2
12.3
19.1
9.5
BCL30019
1/4’’
22.6
4
Conexiones BCL30023 1/0 5/16’’ 50.0 20.7 19.0 22.6 13.5 CU
CU
9.5
15.9
2
9.5
20.7
22.6
BCL30032
3/8’’
54.8
CU
22.2
20.7
60.2
BCL30036
9.5
3/8’’
2/0
28.2
CU
23.0
66.8
1/2’’
3/0
23.8
28.2
BCL30041
CU
BCL30045
JG240N 4/0 1/2’’ 65.9 24.6 24.0 28.2 13.5 CU
Checkman
Terminal tubular 400/450 MCM 1 hueco
JG500N Terminal tubular 800/100 MCM 1 hueco Checkman
TERMINAL TUBULAR
98088N Terminal tubular 2 AWG 5/16” 2 huecos UL Oec
98094N Terminal tubular 1/0 AWG 5/16” 2 huecos UL Oec
98099N Terminal tubular 3/0 AWG 5/8” 2 huecos UL Oec
98104N Terminal tubular 250 MCM 1/2” 2 huecos UL Oec
98106N Terminal tubular 350 MCM 1/2” 2 huecos UL Oec
98107N Terminal tubular 400 MCM 1/2” 2 huecos UL Oec
VS85N Terminal horqueta 8 AWG 7/32’’ Rojo (100 Und) Checkman
BM1875 Terminal faston macho aislada 16 - 14 AWG Azul ( 100 Und) Checkman
Bornas y accesorios
BORNA DE CONEXION JXB0235 Borna de conexion, 2.5 mm, 32 Amp, 600V AC, gris UTL
JXB0435 Borna de conexion, 4 mm, 41 Amp 600V AC, gris UTL
JXB0635 Borna de conexion, 6 mm, 57 Amp 600V AC, gris UTL
JXB1035 Borna de conexion, 10 mm, 57 Amp 600V AC, gris UTL
JB0635 Borna para �erra , 6 mm, 40 Amp,300V AC, verde/amarilla UTL
JB1035 Borna para �erra, 10 mm, 76 Amp, 300V AC verde/amarilla UTL

SKJ4RD Borna porta fusible, 5x20 mm,800V AC negra UTL
ST160 Borna de presión, 24 - 10 AWG, 41A 800V AC riel Sms
JFB1025 Puente para borna, 2.5mm x 10 tornillos UTL
JFB1004 Puente para borna, 4 mm x 10 tornillos UTL
JFB1006 Puente para borna, 6 mm x 10 tornillos UTL
BORNA PARA TIERRA JFB1010 Puente para borna, 10 mm x 10 tornillos UTL
SKJ2G2 Freno para riel con doble tornillo de fijacion UTL
JUT2510 Tapa final para borna, 2.5 x 10 mm, gris UTL
ST14T Tapa lateral para borna ST 140 Sms
ST16T Tapa lateral para borna ST 160 Sms
Riel y freno para riel
ROL351 Riel omega en aluminio 35mm x 0.75mm long 1 mt Checkman
ROA351 Riel omega cold rolled 35mm x 0.75mm long 1 mt Checkman
SKJ4RD ROA352 Riel omega cold rolled 35mm x 0.75mm long 2 mt Checkman
SKJ2G2 Freno para riel Sms

JFB Freno para Riel Tapa para borna ROL351 ROA351/52
